Boya BY-XM6-K1 Kit de Micrófono Inalámbrico Compacto
Kit Incluye:
Transmisor
Receptor
Estuche Cargador
TX Transmisor
Transmission Type | 2.4GHz Digital Frequency |
Modulation | GFSK |
Operating Range (without obstacle) | Up to 328ft (100m) |
RF Output Power | <10mW |
Polar Pattern | Omnidirectional |
Frequency Response | 50Hz-18KHz |
Maximum SPL | Built-in Microphone: 120dB SPL |
Lavalier Microphone: 110dB SPL | |
Sensitivity | Built-in Microphone: -39dB |
Lavalier Microphone: -39dB | |
SNR | > 84dB |
Power Requirements | Built-in Li-ion Battery or USB-C DC 5V or Charging Contact |
Built-in Battery Life | Approx. 7 hours |
Antenna | PIFA Antenna |
Audio Inputs | 3.5mm TRS MIC/LINE IN Jack or Built-in Microphone |
Weight | Approx. 32g(1.13oz) |
Dimensions | 62.1×31.6×16.5mm |
Operating Temperature | –10°C to 50°C |
Storage Temperature | –20°C to +55°C |
RX Receptor
Transmission Type | 2.4GHz Digital Frequency |
Modulation | GFSK |
Operating Range (without obstacle) | Up to 328ft (100m) |
Audio Output Connector | 3.5mm Headphone Jack |
3.5mm TRS Output Jack | |
Audio Output Level | –60 dBV to -20dBV |
Power Requirements | Built-in Li-ion Battery or USB-C DC 5V or Charging Contact |
Built-in Battery Life | Approx. 6.5 hours |
Antenna | PIFA Antenna |
Weight | Approx. 32g(1.13oz) |
Dimensions | 62.1×31.6×16.5mm |
Operating Temperature | –10°C to 50°C |
Storage Temperature | –20°C to +55°C |
Estuche cargador
Power Requirements | USB-C DC 5V/1.5A |
Power Capacity | 2000mAh |
Box’s Charging Time | 3 hours |
Weight | 152g |
Dimensions | 96×96.8×35.6mm |
Operating Temperature | -10°C to 50℃ |
Storage Temperature | -20°C to +55℃ |
